PLUSTEK OpticFilm 8200i AI film scanner

Image Sensor

CCD

Light Source

LED

Hardware Resolution

7200 dpi

Scan Modes

Color: 48-bit input, 24/48-bit output

Grayscale: 16-bit input, 8/16-bit output

B/W: 1-bit

Dynamic Range

3.6

Infrared

Built-in

Scanning Speed

3600 dpi: Approx. 36 sec (Multi-Sampling ON)

7200 dpi: Approx. 113 sec (Multi-Sampling ON)

Scanning Area (W x L)

36.8 mm x 25.4 mm (1.45" x 1")

Preview Speed

Negative Film: Approx. 8 sec (Multi-Sampling ON)

Positive Film: Approx. 8 sec (Multi-Sampling ON)

IT8 Target

Included for color accuracy

Action Button

IntelliScan, QuickScan

Power Supply

15 Vdc / 1.0 A

Interface

USB 2.0

Net Weight

1.6 Kgs (3.5 Lbs)

Dimensions (W x D x H)

120 x 272 x 119 mm (4.73” x 10.7” x 4.7”)

Operating System

Windows 7/ 8/ 10/ 11

Mac OS X 10.7.x/ 10.8.x/ 10.9.x/ 10.10.x/ 10.11.x/ 10.12.x/ 10.13.x/ 10.14.x/ 10.15.x/ 11.x/ 12.x/ 13.x

Hardware Requirements

Windows PC

2 GHz Processor or faster

2 GB RAM main memory (4 GB RAM recommended)

10 GB free space on hard disk drive

CD/ DVD drive or internet connection

Mac

2 GHz Processor or faster (INTEL based processor, NO PowerPC )

2 GB RAM main memory (4 GB RAM recommended)

10 GB free space on hard disk drive

DVD drive or internet connection

Bundled Software

Plustek QuickScan

SilverFast Ai Studio 8
